10/125 NuGEN9 Precision Matched Active LMA Double Clad Fiber
⠀⠀⠀⠀⠀⠀⠀⠀⠀
Smart Product Number: LMA-YDF-10/125-9M
10/125 NuGEN9 Precision Matched Active LMA Double Clad Fiber
NuGEN9 active fibers offer the most advanced glass composition and fiber design and are all precision matched to their passive counterpart ensuring excellent splice compatibility and low loss. This fiber is a Yb-doped Large Mode Area (LMA) active double clad fiber featuring a 10 micron diameter core and 125 micron clad diameter with a low NA (0.08) core. This fiber is ideally suited for applications spanning military, industrial and medical applications. NuGEN9 fibers feature an optimized glass composition enabling higher absorption with superior photodarkening performance. These fibers are proof-tested to 100 kpsi, an industry requirement for long term reliability. NuGEN9 fibers are exclusively offered with Nufern's proprietary NuCOATFA coating technology with the best wet and dry heat performance available, ensuring excellent preservation of beam quality and extended operating life.
