Specifications
Parameter	Unit		Value
Longer Operating Wavelength	nm		2000 ± 20 or Specify
Max. Insertion Loss	dB		0.7
Min. Isolation	dB		13
Min. Extinction Ratio	dB		20
Shorter Operating Wavelength	nm	1570 ± 20	800 ± 20	650 ± 20
Max. Insertion Loss	dB	0.7	0.7	1.5
Min. Isolation	dB	15	15	10
Thermal Stability	dB/℃		≤ 0.005
Min. Return Loss	dB		55
Min. Directivity	dB		55
Max. Optical Power (Continuous Wave)	mW		300
Fiber Type			PM 1550 Panda fiber
Operating Temperature	℃		-5 to +70
Storage Temperature	℃		-40 to +85
