Technical Specs
Travel Range
25.4 mm
Minimum Incremental Motion
<30 nm
Maximum Speed
1.2 mm/min
Axial Load Capacity
22 N
Mounting
9.5 mm Shank
Frequency
2 kHz
Drive Torque
0.018 Nm
Cable Length
2.1 m
Environment
Vacuum
Rated Life
>1x109 steps
Vacuum Compatibility
10-6 Torr
Vacuum Wire Material
Teflon®
Wire Length
45 mm
Operating Temperature
10-40 C
