OPO Crystals
⠀⠀⠀⠀⠀⠀⠀⠀⠀
These crystals can also be used for other applications such as optical parametric generation and optical parametric amplification.
Key features of OPO Crystals
These crystals can also be used for other applications such as optical parametric generation and optical parametric amplification.
- Multi-band AR coated
- Flatness <λ/4@633nm
- Parallel to ±5 minutes
- Better than 70:30 mark-to-space ratio
- Polished to 20-10 scratch dig
- Fewer than two 100μm edge chips per facet
Explore our OPO Crystal range
Want to learn more about our range? OPO (Optical Parametric Oscillator) crystals are available in a variety of wavelengths: MOPO1, MOPO2, and MOPO3: 1064nm pump, signal and idler wavelengths from 1345nm to 5145nm. MOPO515: 515nm pump, signal and idler wavelengths from 640nm to 2530nm.
MOPO1-0.5
Aperture: 0.5 x 0.5 mm
Pump range: 1064 nm
Signal range: 1480-2128 nm
MOPO1-1.0
Aperture: 1.0x 1.0 mm
Pump range: 1064 nm
Signal range: 1480-2128 nm
MOPO2-1.0
Aperture: 1.0 x 1.0 mm
Pump range: 1064 nm
Signal range: 1342-1460 nm
MOPO3-1.0
Aperture: 1.0 x 1.0 mm
Pump range: 1064 nm
Signal range: 1430-2085 nm
MOPO515-0.5
Aperture: 0.5 x 0.5 mm
Pump range: 515 nm
Signal range: 640-1030 nm
