Laser Mirror #103529

Fused silica (IR) | pl-concave | Ø=12.7(-0.1)mm |

te=6.35(±0.10)mm | //<5min

S1: commercial polish | chamfer 0.3 uncoated

S2(^): r=5000mm(±1%) CC | Øe10 | 3/-(0.2) [L/10 reg.] | 5/1x0.025;

L1x0.004 | chamfer 0.3 HR(0°,2940nm)>99.8%
