Monochrome LED optic modules STAR-065 EVM
⠀⠀⠀⠀⠀⠀⠀⠀⠀
The monochrome LED light engines are designed for use with LightCrafter™6500 evaluation modules. The DLP6500 chipset features a 1080p DMD and the DLPC900 controller which is basically different from the high-performance DLP® Discovery™4100 products. The application potential of DLPC900 is focused on two typical use cases:
LightCrafter™ & DMD Chips
ViALUX offers two monochrome LED light engines. Both units are accessories for the LightCrafter™6500 EVMs:
The two light engines differ in the DMD package and mounting concept.
The Type A package is equivalent to the Discovery™ chipset package and enables:
The s600 package is a cost‑efficient model for visible use at > 420 nm wavelength and for moderate light power density.
Delivery and application
The STAR-065 EVM monochrome LED light engines are based upon the STAR CORE optics and integrate a high-power BigChip™ LED including the ViALUX digital LED driver for up to 24 A.
Following wavelength selection is available:
The ViALUX LED driver of the STAR‑065 EVM is controlled by I²C commands for setting the LED current and reading the LED thermistor output. Sample script files are provided for instant use with the LightCrafter™6500 GUI.
The light output is typically 35% less compared to the STAR‑07 due to the smaller active mirror area of the 0.65”DMD with 16:9 aspect ratio.
See STAR-07 Specification for details.
