Name: GREEN LED (515 - 555 nm)
Availability: InStock

GREEN LED (515 - 555 nm)

⠀⠀⠀⠀⠀⠀⠀⠀⠀

Features

- High optical efficiency

- Point source chip

- High optical precision

- AlN submount

Applications

- Industry

- Sensor

- Medical

- Light grids

Product	Typ. Wavelength	Typ. Brightness	Measurement Current	LED Size	Radiation Angle	Data Sheet
LA PM240TGD	520 nm	6 mW	20 mA	0.8 x 1.6 mm	140 °	☞
LA TM120TGG	525 nm	4 mW	20 mA	5.3 mm	120 °	☞
LA BM10TGM	527 nm	7000 mlm	50 mA	7 mm	10 °	☞
LA PL150TGD	527 nm	5 mW	20 mA	0.5 x 1.0 mm	120 °	☞
LA PL240TGD	527 nm	5 mW	20 mA	0.8 x 1.6 mm	140 °	☞
LA RM120TGM	527 nm	7500 mlm	50 mA	5.5 mm	120 °	☞
LA OM5090TGM	527 nm	8000 mlm	50 mA	5.5 mm	50 / 90 °	☞
LA AT020SGH	527 nm	1500 lm	1000 mA	32 x 23 mm	20 °	☞
LA RM40TGM	535 nm	8000 mlm	50 mA	5.5 mm	40 °	☞
LA TM120PGG	540 nm	2 mW	20 mA	5.3 mm	120 °	☞
LA BM10PGM	545 nm	8000 mlm	50 mA	7 mm	10 °	☞
LA RL10PGG	545 nm	6 mW	20 mA	5.5 mm	10 °	☞
LA BL10PGG	545 nm	8 mW	20 mA	7 mm	10 °	☞
LA AT020PGH	550 nm	3400000 mlm	1000 mA	32x23 mm	20 °	☞
