WHITE LED CHIPS (2500 - 10000 K)

Name: WHITE LED CHIPS (2500 - 10000 K)
Availability: InStock

⠀⠀⠀⠀⠀⠀⠀⠀⠀

Features

- Highest brightness InGaN white chip

- Chip level white conversion

- Several CRI level available

- Top emitting device

- Optimized for SMT applications

- Grouping: luminous flux, color coordinates

Applications

- LCD backlighting

- Lamps

- Displays

- Light indicators

Product	Typ. CCT	Typ. Brightness	Measurement Current	Size	Typ. Chip Height	Polarity	Data Sheet
LA WW20WP6	3000 K	45000 mlm	175 mA	500 µm	170 µm	p side up	☞
LA SW43FP6_WW	3000 K	90000 mlm	350 mA	1075 µm	195 µm	n+p side down	☞
LA WW40WP3	3000 K	50000 mlm	350 mA	1000 µm	200 µm	n side up	☞
LA WW40WP4	3000 K	55000 mlm	350 mA	1000 µm	200 µm	n side up	☞
LA WW60SP3	3000 K	160000 mlm	1000 mA	1590 µm	200 µm	n side up	☞
LA HW43FP6_WW	3000 K	80000 mlm	350 mA	1075 µm	195 µm	n+p side down	☞
LA WW53SP6	3000 K	110000 mlm	350 mA	1350 µm	170 µm	p side up	☞
LA WW40WP5	3000 K	80000 mlm	350 mA	950 µm	170 µm	n side up	☞
LA WW40WP6	3000 K	100000 mlm	350 mA	950 µm	170 µm	p side up	☞
LA WW80SP6	3000 K	200000 mlm	700 mA	1930 µm	220 µm	p side up	☞
LA SW43FP6_NW	4000 K	90000 mlm	350 mA	1075 µm	195 µm	n+p side down	☞
LA HW43FP6_NW	4000 K	80000 mlm	350 mA	1075 µm	195 µm	n+p side down	☞
LA CW20WP3	5500 K	25000 mlm	140 mA	500 µm	200 µm	n side up	☞
LA HW43FP6_CW	5500 K	80000 mlm	350 mA	1075 µm	195 µm	n+p side down	☞
LA CW53SP6	5500 K	130000 mlm	350 mA	1350 µm	170 µm	p side up	☞
LA CW28WP6	5500 K	110000 mlm	350 mA	700 µm	170 µm	p side up	☞
LA CW80SP6	5500 K	230000 mlm	700 mA	1930 µm	220 µm	p side up	☞
LA CW20WP6	5500 K	55000 mlm	175 mA	500 µm	170 µm	p side up	☞
LA CW40WP3	5500 K	70000 mlm	350 mA	1000 µm	200 µm	n side up	☞
LA CW40WP6	5500 K	115000 mlm	350 mA	950 µm	170 µm	p side up	☞
LA CW40WP5	5500 K	100000 mlm	350 mA	950 µm	170 µm	n side up	☞
LA UW60SP3	5500 K	200000 mlm	1000 mA	1590 µm	200 µm	n side up	☞
LA UW40WP4	5500 K	90000 mlm	350 mA	1000 µm	200 µm	n side up	☞
LA UW40WP3	5500 K	70000 mlm	350 mA	1000 µm	200 µm	n side up	☞
LA CW60SP3	5500 K	200000 mlm	1000 mA	1590 µm	200 µm	n side up	☞
LA SW43FP6_CW	5500 K	90000 mlm	350 mA	1075 µm	195 µm	n+p side down	☞
