Engineered for cost-effective 200W output for cutting, perforating, and drilling applications. The fully integrated laser/RF design minimizes size and weight; perfect for mounting on robotic arms and high-speed marking systems, or full integration into flatbed cutting systems. With fully integrated RF supplies and clean, simple interfaces to water-cooling and control signals, f Series lasers minimize integration time while providing maximum flexibility for system designers, OEM manufacturers, and full turnkey system providers.
f Series: 200W Lasers
Engineered for cost-effective 200W output for cutting, perforating, and drilling applications. The fully integrated laser/RF design minimizes size and weight; perfect for mounting on robotic arms and high-speed marking systems, or full integration into flatbed cutting systems. With fully integrated RF supplies and clean, simple interfaces to water-cooling and control signals, f Series lasers minimize integration time while providing maximum flexibility for system designers, OEM manufacturers, and full turnkey system providers.
| Model | f201 |
|---|---|
| Output Power | >180W @ 10.2 µm >200W @10.6 µm |
| Mode Quality | M2 < 1.2 |
| Rise Time | < 150 µsec |
| Beam Diameter | 4.5 mm + 0.1 mm |
| Beam Divergence (full angle) | 4.0mR + 0.2mR |
| Wavelength | 10.2 µm/10.6 µm |
| Power Stability from cold start (guaranteed)/after 2 min. (typical) | +7%/+5% |
| Cooling | Water |
| Heat Load (max) | 4000W |
| Input Voltage/Current | 96 VDC/36A |
| Dimensions inches (mm) | 45.9 x 8.6 x 6.5 (1166 x 218 x 165) |
| Weight | 96 lbs./43.5 kg |
| Data Sheet | Click here to download |
| Technical Drawing | Click here to download |
| Product Revision Change Notice | Click here to download |
| Manual | Click here to download |
| Product | Description | Go To |
|---|---|---|
| Power Supply | Recommended DC power supply for Synrad lasers | Click here for more info |
